Advantages for you and the environment
As a manufacturer of shipping packaging, we are naturally aware of our ecological responsibility. As part of our development and production processes, we are always working to optimize and conserve resources.
For example, the electricity consumption of our production is largely covered by self-produced solar power. Of course, the purchased electricity also comes 100% from renewable sources. The focus is also on sustainability in the choice of insulation materials. The INNOBox and INNOBag product lines set the standard here. With a specially embossed recycled paper as insulator, a 100% recycled and furthermore renewable raw material is used.
The SMARTLINER and SMARTCOOLER impress with particularly good insulation values and maximum flexibility with regard to customer-specific formats. The insulator is an insulating fleece consisting of 80% recycled polyester fibers. This means that for every kilo of raw material, 17.5 old PET bottles are put to a new use.
Our range of particularly sustainable solutions is rounded off by our water-based coolpacks. Dispensing with the gelling agent allows end customers to simply dispose of the tap water it contains in the sink and recycle the film.
Innobox 20/40
The sustainable alternative to the conventional polystyrene box.
Our INNOBox is ideal for transporting fresh food and is characterized by an excellent environmental balance. It consists of almost 100% recycled cellulose and is therefore completely recyclable. Since the raw material is also renewable, you can really talk about a completely sustainable solution - INNOvativ and INNOcent.
Advantages
- 100% sustainable raw materials
- Transparently qualified cooling performance
- Logistics optimized by flat delivery (up to 300 boxes per pallet!)
- Big savings in recycling compared to disposable styrofoam packaging
- Easiest disposal in paper recycling
Standard formats INNOBox 20
| Description | Inner dimensions outer carton [mm] | Inner dimensions of cooling room [mm] | Boxes / pallet incl. outer carton | Boxes / pallet excl. outer carton* |
Outer cartons / pallet |
|---|---|---|---|---|---|
| 7,5 L / 20 mm | 277 x 227 x 230 | 230 x 180 x 180 | 120 | 297 | 1.056 |
| 15 L / 20 mm | 347 x 267 x 270 | 300 x 220 x 220 | 80 | 160 | 510 |
| 20 L / 20 mm | 447 x 267 x 270 | 400 x 220 x 220 | 80 | 140 | 510 |
| 30 L / 20 mm | 427 x 327 x 330 | 380 x 280 x 280 | 60 | 120 | 510 |
| 40 L / 20 mm | 427 x 362 x 365 | 380 x 315 x 315 | 60 | 110 | 255 |
*The required outer cartons are delivered on a separate pallet
Standard formats INNOBox 40
| Description | Inner dimensions outer carton [mm] | Inner dimensions of cooling room [mm] | Boxes / pallet excl. outer carton | Outer cartons / pallet |
|---|---|---|---|---|
| 7,5 L / 40 mm | 317 x 267 x 270 | 230 x 180 x 180 | 80 | 520 |
| 15 L / 40 mm | 387 x 307 x 310 | 300 x 220 x 220 | 70 | 520 |
| 20 L / 40 mm | 437 x 327 x 330 | 350 x 240 x 240 | 60 | 520 |
| 30 L / 40 mm | 407 x 392 x 395 | 320 x 305 x 305 | 50 | 260 |
| 40 L / 40 mm | 467 x 402 x 405 | 380 x 315 x 315 | 45 | 260 |
Innoliner
The INNOLiner is a sustainable insulating liner made from several layers of embossed recycled paper, wrapped in kraft paper. Sewn on the the narrow and long sides, it offers reliable protection.
Benefits for you and the environment
- 100% freshness thanks to qualified insulation performance
- Robust and tear-resistant kraft paper wrapping
- 100% sustainability thanks to the use of 100% renewable, recyclable and biodegradable raw materials
- Customised products incl. individual branding possible
- Suitable for B2B and B2C
- Suitable for the dispatch of food and pharmaceuticals, cosmetics and pet food
Standard formats INNOLiner
| Description | Dimensions outer carton [mm] | Dimensions INNOLiner [mm] | Usable volumen in litres | Boxes / pallet excl. outer carton |
|---|---|---|---|---|
| INNOLiner S | 300 x 300 x 200 | 230 x 180 x 180 | 16 | 180 |
| INNOLiner M | 300 x 300 x 300 | 300 x 220 x 220 | 24 | 150 |
| INNOLiner L | 400 x 400 x 200 | 400 x 220 x 220 | 29 | 150 |
| INNOLiner XL | 400 x 400 x 300 | 380 x 280 x 280 | 44 | 90 |
Cooling time with recommended quantity of coolpacks (CPs)
| Description | Type and number of CPs | Cooling time < 4°C [h] | Cooling time < 8°C [h] |
|---|---|---|---|
| INNOLiner S | 6 x 2.1 - 500 g | 25:00 | 40:45 |
| INNOLiner M | 4 x 1.3 - 900 g | 39:15 | 46:15 |
| INNOLiner L | 4 x 1.3 - 900 g | 41:00 | 48:35 |
| INNOLiner XL | 5 x 1.3 - 900 g | 32:50 | 48:05 |
Smartliner
With the SMARTLINER, we’ve developed a highly cost-effective and sustainable form of insulation – made from recycled PET – for complete boxes. Thanks to added cooling elements, it keeps things cool for over 48 hours. The SMARTLINER is ideal for shipping foodstuffs, pharmaceutical products, cosmetics and animal feed.
Benefits
- Safe and affordable
- Sustainable, thanks to its use of recycled materials
- Customer-specific bespoke manufacture possible, incl. individual branding
- Suitable for B2B and B2C
- Suitable for shipping foodstuffs and medicines, cosmetics and animal feed
Properties
- Material: The fleece is composed of 100% polyester fibres
- Proportion of recycled material: 80%
- Colour: white/brown/flecked with black -> colours may vary due to recycled fibres
- Thermal conductivity: 0.038 W/m K
- Surface weight: 400 g/m²
Current standard formats
| Size | Dimensions (mm) |
|---|---|
| S | 360 x 200 x 210 |
| M | 400 x 300 x 250 |
| L | 580 x 380 x 200 |
| XL | 580 x 380 x 300 |
Tolerance of all dimensions ± 3%
Recommended number of coolpacks
| Smartliner | Time ≤ 4°C | Time ≤ 8°C | Type and no. of CPs |
|---|---|---|---|
| S | 24:25 h | 44:50 h | 4x CP 4.1, 500 g |
| M | 38:25 h | 48:40 h | 4 x CP 1.3, 900 g |
| L | 41:05 h | 54:10 h | 6 x CP 1.3, 900 g |
| XL | 44:00 h | 53:35 h | 8 x CP 1.3. 900 g |
INNOBag
100% logistics-optimized, especially for joint shipping with dry goods.
Our INNOBag is a brand new addition to the range. It is ideal for transporting fresh food and is characterized by an excellent environmental balance. It consists of almost 100% recycled cellulose and is therefore completely recyclable. Since the raw material is also renewable, you can really talk about a completely sustainable solution - INNOvativ and INNOcent.
| Description | Dimensions [mm] | Pieces / box | Pieces / pallet |
|---|---|---|---|
| INNOBag S | 300 x 380 | 100 | 600 |
| INNOBag M | 500 x 380 | 60 | 360 |
| INNOBag L | 500 x 500 | 50 | 300 |
Smartcooler
The Smartcooler was developed for parcel shipping of temperature-sensitive goods and provides in combination with cooling elements a temperature profile of <4 °C over 30-40 hours transit time at ambient temperatures of 18-30°C. In combination with adequate boxes, it allows combined packing of chilled and non-chilled goods in one unit.
Quick overview
- Designed for parcel shipping of fresh food: < 4 °C over 30- 40 hours
- Sustainable design by PE fleece made from 80% recycled material
- 3 standard sizes available from stock
- Perfectly matching with ECOCOOL Coolpack elements
The following standard sizes are always available:
- S = 350 x 365 mm
- M = 480 x 360 mm
- L = 530 x 445 mm
