Food cooling packaging
Cooling Boxes
Innobox 20/40
The sustainable alternative to the conventional polystyrene box.
Our INNOBox is a brand new addition to our range. It is ideal for transporting fresh food and is characterized by an excellent environmental balance. It consists of almost 100% recycled cellulose and is therefore completely recyclable. Since the raw material is also renewable, you can really talk about a completely sustainable solution - INNOvativ and INNOcent.
Advantages
- 100% sustainable raw materials
- Transparently qualified cooling performance
- Logistics optimized by flat delivery (up to 300 boxes per pallet!)
- Big savings in recycling compared to disposable styrofoam packaging
- Easiest disposal in paper recycling
Standard formats INNOBox 20
| Description | Inner dimensions outer carton [mm] | Inner dimensions of cooling room [mm] | Boxes / pallet incl. outer carton | Boxes / pallet excl. outer carton* |
Outer cartons / pallet |
|---|---|---|---|---|---|
| 7,5 L / 20 mm | 277 x 227 x 230 | 230 x 180 x 180 | 120 | 297 | 1.056 |
| 15 L / 20 mm | 347 x 267 x 270 | 300 x 220 x 220 | 80 | 160 | 510 |
| 20 L / 20 mm | 447 x 267 x 270 | 400 x 220 x 220 | 80 | 140 | 510 |
| 30 L / 20 mm | 427 x 327 x 330 | 380 x 280 x 280 | 60 | 120 | 510 |
| 40 L / 20 mm | 427 x 362 x 365 | 380 x 315 x 315 | 60 | 110 | 255 |
*The required outer cartons are delivered on a separate pallet
Standard formats INNOBox 40
| Description | Inner dimensions outer carton [mm] | Inner dimensions of cooling room [mm] | Boxes / pallet excl. outer carton | Outer cartons / pallet |
|---|---|---|---|---|
| 7,5 L / 40 mm | 317 x 267 x 270 | 230 x 180 x 180 | 80 | 520 |
| 15 L / 40 mm | 387 x 307 x 310 | 300 x 220 x 220 | 70 | 520 |
| 20 L / 40 mm | 437 x 327 x 330 | 350 x 240 x 240 | 60 | 520 |
| 30 L / 40 mm | 407 x 392 x 395 | 320 x 305 x 305 | 50 | 260 |
| 40 L / 40 mm | 467 x 402 x 405 | 380 x 315 x 315 | 45 | 260 |
Smartliner
With the SMARTLINER, we’ve developed a highly cost-effective and sustainable form of insulation – made from recycled PET – for complete boxes. Thanks to added cooling elements, it keeps things cool for over 48 hours. The SMARTLINER is ideal for shipping foodstuffs, pharmaceutical products, cosmetics and animal feed.
Benefits
- Safe and affordable
- Sustainable, thanks to its use of recycled materials
- Customer-specific bespoke manufacture possible, incl. individual branding
- Suitable for B2B and B2C
- Suitable for shipping foodstuffs and medicines, cosmetics and animal feed
Properties
- Material: The fleece is composed of 100% polyester fibres
- Proportion of recycled material: 80%
- Colour: white/brown/flecked with black -> colours may vary due to recycled fibres
- Thermal conductivity: 0.038 W/m K
- Surface weight: 400 g/m²
Current standard formats
| Size | Dimensions (mm) |
|---|---|
| S | 360 x 200 x 210 |
| M | 400 x 300 x 250 |
| L | 580 x 380 x 200 |
| XL | 580 x 380 x 300 |
Tolerance of all dimensions ± 3%
Recommended number of coolpacks
| Smartliner | Time ≤ 4°C | Time ≤ 8°C | Type and no. of CPs |
|---|---|---|---|
| S | 24:25 h | 44:50 h | 4x CP 4.1, 500 g |
| M | 38:25 h | 48:40 h | 4 x CP 1.3, 900 g |
| L | 41:05 h | 54:10 h | 6 x CP 1.3, 900 g |
| XL | 44:00 h | 53:35 h | 8 x CP 1.3. 900 g |
ISOHOOD-INLAY-System
Our solution for parcel distribution of fresh foods: ECOCOOL`S ISOHOOD-INLAY COOLING PACKAGING system was developed for the specific requirements of fresh food distribution. It guarantees < 8°C temperature control over 30-40 hours.
Benefits
- Space-saving, delivered flat: up to 500 packs per pallet
- 7 readily available standard formats
- Suitable for use with ECOCOOL Coolpack cooling elements
- Customer-specific dimensions available
- Easy to use, secure and cost-efficient
| Type | Dims (mm) | Packaging pcs./pal. with cardboard/inlays only |
Required Coolpacks |
|---|---|---|---|
| M01 | 260 x 160 x 120 | 500/800 | 3 St. 2.4/4.1 |
| M02 | 360 x 200 x 210 | 250/400 | 5 St. 3.1 |
| M03 | 400 x 300 x 250 | 150/250 | 3 St. 1.3 |
| M04 | 290 x 210 x 90 | 500/800 | 2 St. 2.1 |
| M05 | 290 x 210 x 180 | 250/500 | 3 St. 2.1 |
| M06 | 580 x 380 x 200 | 150/250 | 4 St. 1.3 |
| M07 | 580 x 380 x 300 | 130/250 | 6 St. 1.3 |
Cooling bags
INNOBag
100% logistics-optimized, especially for joint shipping with dry goods.
Our INNOBag is a brand new addition to the range. It is ideal for transporting fresh food and is characterized by an excellent environmental balance. It consists of almost 100% recycled cellulose and is therefore completely recyclable. Since the raw material is also renewable, you can really talk about a completely sustainable solution - INNOvativ and INNOcent.
| Description | Dimensions [mm] | Pieces / box | Pieces / pallet |
|---|---|---|---|
| INNOBag S | 300 x 380 | 100 | 600 |
| INNOBag M | 500 x 380 | 60 | 360 |
| INNOBag L | 500 x 500 | 50 | 300 |
Smartcooler
The Smartcooler was developed for parcel shipping of temperature-sensitive goods and provides in combination with cooling elements a temperature profile of <4 °C over 30-40 hours transit time at ambient temperatures of 18-30°C. In combination with adequate boxes, it allows combined packing of chilled and non-chilled goods in one unit.
Quick overview
- Designed for parcel shipping of fresh food: < 4 °C over 30- 40 hours
- Sustainable design by PE fleece made from 80% recycled material
- 3 standard sizes available from stock
- Perfectly matching with ECOCOOL Coolpack elements
The following standard sizes are always available:
- S = 350 x 365 mm
- M = 480 x 360 mm
- L = 530 x 445 mm
COOLMAILER
The flexible and economic solution for the dispatch of temperature-sensitive food products. The COOLMAILER ensures customers receive products such as chocolate, fish and fresh meat always in a cooled condition.
The COOLMAILER is available in different sizes and can be combined with cooling elements to provide a flexible solution for the dispatch of sensitive products under cooled conditions. The cold chain can be guaranteed for more than 24 hours using the COOLMAILER along with the necessary number of Coolpacks. The thermal coverings are available in different sizes and have been specially developed for parcel dispatch. They offer optimal utilisation of space and enable dispatch in a single package of both dry goods and goods requiring cooling. An adhesive flap provides easy handling and, when sealed, prevents unwanted air leakages.
The following standard sizes are always on stock (basic dimensions, 4cm for sealing flap in brackets):
- 25x18 (+5) cm
- 40x40 (+5) cm
- 60x40 (+5) cm (minimum order quantity: 250)
Other sizes can be requested from a minimum order quantity of 1000.
